481/91/92/93 |
|||||
|
Genset model |
AYQ-4DW81-23D-YDF10W |
AYQ-4DW91-29D-YDF10W |
AYQ-4DW92-35D-YDF10W |
AYQ-4DW93-42D-YDF10W |
|
|
Prime power(KW/KVA) |
12/15 |
16/20 |
20/25 |
24/30 |
|
|
Standby power(KW/KVA) |
13/16 |
18/23 |
22/28 |
27/34 |
|
|
Weight(kg) |
240 |
260 |
|||
|
Dimension(L*W*H/mm) |
1950*900*1150 |
||||
|
Engine |
Model |
4DW81-23D-YDF10W |
4DW91-29D-YDF10W |
4DW92-35D-YDF10W |
4DW93-42D-YDF10W |
|
Bore*Stroke(mm) |
85*95 |
90*100 |
|||
|
Cyl No. and Arrangement |
4-Cyl L-line |
||||
|
Speed(r/min) |
1500/1800 |
||||
|
Warranty |
12 Months / 1000 Hours |
||||
|
Quality Control |
The products have been rigorously tested |
||||
|
Payment |
T/T, Western Union, Alibaba online payment. |
||||
|
Service |
Guidance on product issues through online and video support |
||||
